Round Summary
On the Drillholes Summary tab of the Plot Options form, choose which round summary totals to include in (or excluded from) the plot.
The Round Summary is a table which summarises the main properties of the round, including the heading surface area, total number of drillholes, total drillhole meters and the total Mass of Explosives used in the round.
Display
Select these check boxes to enable or disable the display of the summary fields listed. To display all fields, select the Select All check box.
Expression
This column displays the fields from the blocks summary database to be displayed. To change the expression for the field, click the Expression icon at the right of the cell.
Display Field Name
This column displays the name of the field as it will be displayed in the blast design plot. To edit the display name for a field, double-click on the cell to make it editable.
Decimals
This column displays the number of decimal places to which the value for the field will be displayed. Where applicable, you can click inside the Decimals column and change the number of decimals to be used.
Report Number of Holes by Type
Select this check box to report the number of holes, grouped by Hole Type,
