Convert to TDB File

On the Wireframe tab, in the Manage group: Select Convert to TDB File to convert wireframe types that have been created or saved in the new .tridb format to the old .TDB format. This conversion is provided for backward compatibility.

To manually convert your wireframe types to the old format:

  1. In the Convert Wireframe Type form:

    2. Double-click in the Input Type box to select the type you want to convert. Enter (or click on the ellipsis to select) the name of the Output Type.

  1. Enter (or click on the ellipsis to select) the name of the Error Report File that will generated as a result of the Conversion process.
  2. Finally, click OK to begin the conversion. A message is displayed on completion:
